Uses and Applications.
Workholding
Create custom fixtures to hold any part with ease, letting you focus on machining.
Composites
Build, trial and change geometries without sinking time and money into fixed moulds.
Vacuum Forming
Eradicate tooling delays and enjoy unlimited mould iterations, all at a fraction of the cost.
Workholding
Create custom fixtures to hold any part with ease, letting you focus on machining.
Composites
Build, trial and change geometries without sinking time and money into fixed moulds.
Vacuum Forming
Eradicate tooling delays and enjoy unlimited mould iterations, all at a fraction of the cost.
A step-change in workflow flexibility.
PolyMorphic Forming replaces traditional tooling with a digitally controlled pin array, converting CAD designs into physical parts in minutes.
Detatchable Tool
Move it between machines, projects, or locations with ease.
Waste-Free Process
Eliminates disposable tooling materials which replaces waste with a clean, digital process.
Forms in Minutes
Thousands of digitally controlled pins adapt in real time, turning design changes into production reality.
Uses and Applications.
Workholding
Deliver parts up to 10x faster than traditional tooling or wax-room methods.
Composites
Automated, configurable systems support lights-out, uninterrupted production.
Vacuum Forming
Begin production immediately with tool-free forming and no mould preparation.
A step-change in workflow flexibility.
Detatchable Tool
Move it between machines, projects, or locations with ease.
Waste-Free Process
Eliminates disposable tooling materials which replaces waste with a clean, digital process.
Forms in Minutes
Thousands of digitally controlled pins adapt in real time, turning design changes into production reality.
PolyMorphic Forming replaces traditional tooling with a digitally controlled pin array, converting CAD designs into physical parts in minutes.
Technical Specifications
Inside the Machine
DOWNLOAD PDF
00
SPECS
FORMING AREA:
RESOLUTION:
SETUP TIME:
RECONFIGURATION SPEED:
CONTROL SYSTEM:
APPLICATIONS:
250MM X 350MM x 60mm
1.5MM PIN PITCH
<5 MIN
10min per mould
FYOUS 0SV2
orthotics, medical, moulds
WORKING STEPS
01
Load your STL file via PinPoint.
02
PolyMorphic tool forms to your design.
03
Remove and transfer the tool to your preferred workspace.
04
Reinsert the tool to be reconfigured for your next design.
SPEC
x:350 y:155 z:50
<20 mins per mould
6 tonnes
???
Yes
28,224
0.8mm
1.4mm
+-0.1mm
23kg
Working volume (mm)
Forming time
Max holding force (distributed)
Max holding force (per square inch)
Water/coolant resistant
Pin quantity
Pin diameter
Pin pitch
Pin Z axis repeatability
Tooling mass
